Talbert Manufacturing
4050TA
- Deck length
- 12 ft
Specifications
Construction
- Four Beam, T-1 & 80k Construction
- 4 in. I-Beam Crossmembers on 9 in. Centers
General
- 80,000 lbs. Distributed 50,000 lbs. in 10 ft.
- 1 1/2 in. Apitong Flooring
- 86-in. Swing Radius
- Hub Piloted Steel Disc Wheels
- Planetary Winch with Air-Tensioner, Cable and Shackle
- Tires: 235/75R17.5 (H) 16 PR
- Wireless Winch Remote
- RIDEWELL Air Ride Suspension
- Wet-Line Operation
- 7-Way Plug With LED Lights
- Two-Speed Landing Gear
- Two Pair of Pipe Pockets Inside Side Beam Flange
Dimensions
- Overall Length: 50 ft. 0 in.
- Keyhole Chain Slots in Side Beams and Deck Centerline; both on 36 in. Centers in
- Lower Deck Length: 39 ft. 2 in.
- Eight Keyhole Chain Slots Across Rear Approach Plate in
- Upper Deck Length: 10 ft. 10 in.
- 12 1/4 in. x 7 1/2 in., 2S/1M ABS System in
- Cable Roller at Front, Center of Lower Deck
- Axle Stops on Last Axle to Prevent Crushing when Loading
- 8 ft. – 6 in. Width
- 19,480 lbs.
Capacity
- Large Capacity, Lockable Tool Box on Curb Side with Chain Rack, Updated Hardware and Door Seal
- Valspar R-Cure 800® Top Coat
About traveling axle trailers
On a traveling axle trailer the axle assembly slides forward hydraulically until the rear of the deck touches the ground, turning the whole deck into a ramp. Equipment loads from the rear without a detachable neck or separate ramps, which makes it fast for one operator. Popular with rental yards and contractors moving mid-size machines and containers, with capacities typically from 25 to 55 tons.
Not sure this is the right type for your load? Tell us what you are hauling and we will recommend a capacity and deck.
